Hot Rolled Steel Flat Bar

Hot Rolled Steel Flat Bar in a full range of sizes and grades, with stock lengths, cut-to-length service, third party inspection and mill test certificates on request. Send your size list and destination port for a quote within 12 hours.

Tolerance on flat bar sounds like a rounding error until a fabrication shop has to explain why a thousand brackets will not line up. Ours is held to ±1%, and a machine-frame builder we supply once calculated that the previous supplier's wider tolerance was costing him a full shift of shimming per installation. Hot rolled flat bar is priced like a commodity and behaves like a precision input - the tolerance clause is where the two meet, so it is worth reading before comparing prices.

What hot rolling gives the bar

The bar is rolled to section at high temperature, which fixes the rectangular cross-section and the surface in a single pass sequence. The hot route keeps the process light and the product strong without heat treatment: sections come out dimensionally stable, with the strength and durability that hot-worked carbon steel is known for, at a price per ton that cold-worked profiles cannot touch.

The material menu

hot rolled steel flat bar bundles

The standard carbon ladder - Q195, Q215, Q235, Q345 - covers general fabrication and structural work. Beyond it sit the alloy and machine grades: 20Cr and 40Cr where hardenability matters, and 20CrMo, 35CrMo and 42CrMo for parts that will be quenched and tempered into shafts, pins and high-stress fittings. Being able to quote the whole ladder from one mill is why equipment makers consolidate their flat bar buying here instead of splitting between a structural warehouse and a special-steels trader.

Where each grade lands

Q195 and Q215 feed light frames, hoops and secondary structure. Q235 is the everyday structural and machinery grade. Q345 steps up for load-bearing members. The Cr and CrMo grades go into machined parts - their value shows up after heat treatment, and the mills that roll them control chemistry accordingly. If your drawing names a grade in the alloy list, the bar arrives with the heat analysis to prove it.

Tolerance and what it protects

flat bar width and thickness measurement

±1% on width and thickness is the clause that keeps automated fabrication running: punching lines, press brakes and welding gantries all assume the section matches the setup. The tolerance is verified at dispatch - width and thickness sampled at both bundle ends, values recorded - so a claim, if there ever is one, starts from numbers rather than opinions.

Minimum order and logistics

MOQ is 10 tons, sized so a working inventory lands in one shipment rather than trickling in. Bundles are strapped by section, tagged by heat, and loaded for straightforward unloading at a standard yard crane. Supply standard is ASTM, with other systems quotable when the project's documents name one.

Questions from the buying desk

Can the CrMo grades ship with heat treatment certificates? The heat analysis ships as standard; mechanical results after customer heat treatment depend on the cycle, so we supply chemistry and let your heat treater certify the rest.

Does ±1% apply over the full size range? Yes - it is a percentage clause precisely so it scales from light to heavy sections.

Send the grade and section list

Grades, sections, tonnages, and whether the bar feeds a machine line or a structural shop. The answer tells us which end of the material menu to emphasize, and gets you a quotation with the tolerance and certificates written into it instead of promised after.
